46inch 5.3mm super narrow bezel video wall solution Model：UD-PJ460CZB02

Parameter :

项目内容

Products Detail

1) Samsung unique DID LCD screen, can be placed horizontally, it can also be placed lengthwise;

2) Professional design, suitable for a variety of ways to install, metal shielding mechanism to prevent external electromagnetic interference;

3) LED-backlit display technology, 3500: 1 high contrast, sharp images, no radiation;

4) the need for an external splitter unique stitching technology, progressive input signals can be accurate to split control a pixel;

5) Integrated 3D Decoder, 2Scaler, 8bit digital signal input and output support to the operation control flexibility;

6) Long life, stable operation, no burns, injuries, low maintenance costs;

7) Various input and output interfaces, VGA, DVI, HDMI, AV interface terminals can be accessed by computers and video equipment;

8) The installation of intelligent temperature control system, dual fan design to ensure the internal temperature control in less than 55 degrees, safe and reliable;

9) Simplified Chinese, Traditional Chinese, English and other countries language menu operating system, user-friendly man-machine interface;

10) added support scrolling on the screen subtitles, support for real-time monitoring equipment operating conditions and failure analysis.

Technical parameters:

Model

Samsung 46-inch LCD splicing screen Nanor Machine Model: UD-PJ460CZB02 original panel Model: LTI460HN01

Screen size (mm)

1023.9 * 578.6 * 100 (the whole thickness of 100mm)

Image Aspect Ratio

16:09

Bilateral physical patchwork

5.3mm (3.7mm at the left and right 1.8mm)

Best resolution

1920x1080

Compatible Resolution

1920x1080; 1600x1200; 1366X768; 1280x1024; 1280x768; 1024x768

Pitch

1.53 (H) × 0.53 (V)

Response time

8ms

Color

8 bit, 16.7m

Brightness

500cd/ m

Contrast

3500: 1

Color Temperature

10000K

Viewing angle (H / V)

178/178 degrees

Backlight

WLED backlight

Power supply

AC 100V ~ 240V, 50 / 60Hz, Universal, ± 10%

Power

198W (normal operation)

Life

60,000 hours

Signal Interface

AV VGA DVI HDMI SDI DP YPbPr USB

Standard accessories

Power line

Optional accessories

Rackmount, wall, floor
