55"5.3mm super narrow bezel 1500nits outdoor video wall Model：UD-PJ550CZB02
Parameter :
项目内容
Products Detail
| 55" Specifications | |
| Model No. | PJ550CZB |
| Panel Size | 55'' Samsung DID LCD Screen(narrow bezel 5.3mm) |
| Brightness | 1500nits |
| Max resolution | 1920X1080 |
| Screen Size [inch/cm] | 55 / 138.8 |
| Active Screen Area (W x H) [mm] | 1,210 x 680 |
| Panel Technology | S-PVA TFT with direct white LED backlights |
| Aspect Ratio | 16:9 |
| Color | 8Bit,16.7M |
| Visual Angle (H/V) | 178°/178° |
| Response Time | <=6ms |
| Life(hrs) | >60,000(hrs) |
| Input and output | |
| DVI | 1 |
| HDMI | 1 |
| D15-RGB Input(VGA) | 1 |
| RJ45 | 2 |
| Composit video input(AV) | 2(2xBNC) |
| Composit video input | 2(2xBNC) |
| Split screen | Support picture in picture(PIP/POP/PAP) |
| Power | |
| Power supply | AC100V~240V |
| Maximum power consumption | 230W |
| Standby comsuption | <=3W |
| Temperature | |
| Working temperature | 0℃～50℃ |
| Working Humidity | 20％～80％ |
| Dimension | 121.5*68.6cm |
| Weight | 40kg |
